Wholesale professional Color Coated Aluminum Coils Brushed Rolled Coils supplier
Application:
For its lightweight, beautiful appearance, as well as good anti-correction, color coated aluminum Sheet and Coil are vastly used in Exterior and Interior applications. Color coated aluminum coil are widely used in ACP,curtain panel,honey comb panel,shutter,roofing and most of the decoration areas.
Product Description:
Aluminum has an excellent strength-to-weight ratio and is easy to form. Its natural corrosion resistance, which can be improved by anodizing, is one of its greatest benefits. The aluminum coil has a wide range of applications, from housing siding, trim strips, gutters, and roofing to cans, lids, bottle caps, and other food packaging, appliances, and electronics. Because it is a lightweight and durable material, it can also be found in the automotive industry.
Color coated Aluminum coil means coloring is processed onto the surface of aluminum coil by coating PE or PVDF paints. According to the Surface Coating Of Paint, Color Coated Aluminum Coils Can Be Divided Into Polyester (PE) Coated Aluminum Coil, Fluorocarbon (PVDF) Coating Aluminum Coil And Epoxy Coated Aluminum Coil.
Product Specification:
| Brand： | FODY |
| Product Name： | Pre-painted Color Coated Aluminum Coil |
| Standard | ATSTM B209, JIS H4000-2006,GB/T3190-2008,GB/T3880-2006, etc. |
| Material | 1000 Series:1050,1060,1080,1100,1435,etc. |
| 2000 Series:2011,2014,2017,2024,2A12,2A16,2A06,etc. | |
| 3000 Series:3002,3003,3004,3104,3204,3030,3A21,etc. | |
| 5000 Series:5005,5025,5040,5052,5056,5083,5A05,etc. | |
| 6000 Series:6003,6060,6082,6083,6063,6061,etc. | |
| 7000 Series:7003,7005,7050,7075,etc. | |
| Coating thickness | 14-28 microns（PE：≥14micron，pvdf：≥25micron） |
| Coils core diameter | 150mm,405mm,505mm |
| Coil weight | 1.0 to 3.0 tons per coil |
| Color | white series,metallic series,dark series,gold series(accept color customs)RAL |
| Temper | O, H12, H14, H18, H22, H24, H32, H34, H36,T3,T5,T6,ect |
| Specifications | Thickness: 0.024mm~200mm |
| Width: 100mm~2000mm | |
| Length: 2m,3m,5.8m,6m,or as required | |
| Surface | Bright, polished, hair line, brush, sand blast, checkered, embossed, etching, etc. |
| Price Term | Ex-work, FOB, CIF , CFR, etc. |
| Payment Term | T/T, L/C, Western Union, etc. |
| Delivery Time | 7-14 days |
| Package | Export standard package: bundled wooden box, suit for all kinds of transport, or be required. |
| MOQ | 5 tons |
| Alloy: | AA1100, 3003, 3004, 3105, 5006, 5052, 8011,etc |
| Thickness: | 0.08-4.0mm |
| Width: | ＜1800mm |
| Coils core diameter: | 150mm ,405mm, 505mm, 508mm, 510mm |
| Coating thickness: | PVDF >=25micron POLYESTER>=18micron |
| Color standard: | E < 2 or it is not obvious by eyeballing |
| Pencil hardness: | > 2HB |
| Coating adhesive: | not lower than first grade Impact: no any crack (50kg/cm, ASTMD-2794:1993) |
| Bend stength: | >100 times |
| Boiling point: | no any distortion and color change (in the 99 more or less 1 degree water, then cooling 2 hours) |
| Corrosive: | surface deep in the 5% muriatic acid and 5% NaCL, interior deep in the 2% muriatic acid and 2% NaCL, after 48 hours, no change |
1.Q:What are your major products?
A:Our products cover aluminium profile mechanical equipment, stainless steel tube mill equipment & spare parts, meanwhile we can provide customized service including a complete set of machines like casting plant, ss tube mill line, used extrusion press line, steel pipe polishing machine and so on, both saving clients’time and efforts.
2.Q:Do you provide installation and training service as well?
A:It is workable. We can arrange specialists to assist installation, testing and provide training after you receive our equipment products.
3.Q:Considering this will be a cross-country trade,how can we make sure the product quality?
A:Based on the principle of fairness and trust, site checking before delivery is allowed. You can check the machine through according to the pictures and videos we provide.
4.Q:What documents will be included when delivering the goods?
A:Shipping documents including : CI/PL/BL/BC/SC etc or accoding to client's requirement.
5.Q:How to guarantee the cargo transportation safety?
A:To guarantee the cargo transportation safety, insurance will covers the cargo. If necessary, our people would follow up at the container stuffing location to make sure a tiny part is not missed.
